PVC Air Hose

The PVC air hose is widely used in pneumatic tools, pneumatic washing apparatus, compressors, engine components, machine service, and civil engineering equipment. PVC air hoses are specifically designed for the transfer of compressed air. They are constructed using high-quality PVC material that is reinforced with synthetic fibers for added strength and durability. These hoses are engineered to withstand the rigors of air transfer and deliver consistent performance over time.

  • Tube:  Black Plasticized PVC.
  • Reinforcement: High Tensile Spiral Polyester Yarn.
  • Cover: Ribbed Blended PVC & Smooth PVC.
  • Application: For air, water, and moderate chemical.
  • Temp. Range. :  – 5 ̊C  to +60 ̊C (23°F to 140°F)

Specification of PVC Air Hose

  • Durability: PVC air hoses are built to be highly durable, ensuring longevity even in demanding environments.
  • Flexibility: These hoses offer excellent flexibility, allowing for easy maneuverability and hassle-free handling during air transfer.
  • High Burst Pressure: PVC air hoses are designed to withstand high-pressure applications, preventing bursts or leaks.
  • Lightweight: PVC construction makes the hoses lightweight, reducing fatigue during extended use.
  • Smooth Inner Surface: The smooth inner surface minimizes friction, ensuring efficient airflow and preventing clogs.
Part No. Size I.D. O.D. Length W.P. B.P. Weight
# Inch mm mm m/coil Bar Bar kg/m
SHA06512 1/4″ 6.5 12 100 20 80 0.10
SHA65125 1/4″ 6.5 12.5 100 30 95 0.12
SHA08514 5/16″ 8.5 14 100 20 80 0.13
SHA85145 5/16″ 8.5 14.5 100 30 90 0.14
SHA01016 3/8″ 10 16 100 20 80 0.16
SHA01320 1/2″ 13 20 50 20 75 0.24
SHA01625 5/8″ 16 25 50 20 60 0.38
SHA19285 3/4″ 19 28.5 50 20 50 0.46
SHA25345 1″ 25 34.5 50 15 45 0.58
SHA03244 1-1/4″ 32 44 40 15 45 0.94
SHA03850 1-1/2″ 38 50 40 15 40 1.09
SHA05064 2″ 50 64 40 15 30 1.64

Material and Production of PVC Air Hose

pvc-air-hose-material
pvc-air-hose-manufacturing

Package Style of PVC Air Hose

pvc-air-hose-package
pvc air hose package
